Frequency response 20 Hz to 20 kHz +0, –0.15 dB <0.5 Hz to 100 kHz +0, –3 dB Signal-to-noise ratio >103 dB, wideband, unweighted, referred to full power output >114 dB, “A”-weighted Gain 27 dB Total harmonic distortion <0.03% at 1 kHz, at 375 W, 8 O <0.19% at 20 kHz, at 375 W, 8 O Input Impedance Single-ended: 100 kO Balanced: 200 kO Input sensitivity Single-ended or balanced: 2.45 V RMS Output power 375 W RMS at 8 O 600 W RMS at 4 O Output voltage 154 V peak-to-peak 55 V RMS Output current 17 A peak Slew rate 40 V/µs Output impedance <0.018O, 20 Hz to 20 kHz Damping factor >440, 20 Hz to 20 kHz, referred to 8 Power consumption Standby: 1 W Idle: 66 W Maximum: 1150 W Heat output Standby: 3.42 BTU/hr. Idle: 225 BTU/hr. Maximum: 3933 BTU/hr. Inputs 1 single-ended via RCA connector 1 balanced via XLR connector 1 CAST Outputs 1 pairs binding posts Dimensions 17.1 in. W x 7.65 in. H x 21.10in. D 434 mm W x 194 mm H x 536mm D Weight 70 lbs., 31.8 kg (shipping) 60 lbs., 27.3 kg (unit only)Read More
