HiFi Rose RA 180 Integrated Amplifier

$6,995.00

At a Glance

Reference Integrated Amplifier and Preamp w/ GaN FET Class AD topology, Balanced Power Supply, MM/MC Phono stages Built-in, Variable EQ Tone Control, Level Meters, Motorized Remote Control via IR, Subwoofer Out & Active Crossover

Proposition 65 Warning for California Residents

HiFi Rose RA 180 Integrated Amplifier

POWER: OUTPUT: SMPS (800W) ( Maximum Power: 1,100W ) VOLTAGE: AC100-240V, 50/60Hz (Standby Mode Power Consumption <0.5W) AMPLIFIER OUTPUT: 4 Ω: 200W x 4ch (800W) 8 Ω: 200W x 4ch (880W) BTL Mode On: 400W x 2ch (400W) INPUT SENSITIVITY: BALANCE INPUT: 2,000mV (200W x 4ch) UNBALANCED (Lline 1,2,3) INPUT: 1,000mV ( 200W x 4ch) PHONO (MM/MC) INPUT: 5mV / 0.5mV (200W x 4ch ) IMPEDANCE INPUT: BALANCE INPUT: 44kΩ UNBALANCE (Line 1,2,3) INPUT: 47kΩ PHONO (MM/MC) INPUT: 47kΩ IMPEDANCE OUTPUT: SPEAKER OUTPUT: 53MΩ ( 200W X 4ch ) BANDWIDTH (0dBr+/-3dB/8Ω): SPEAKER OUTPUT: 10HZ - 100KHZ ( 100W X 2ch ) H/F SPEAKER OUTPUT: 10HZ - 100KHZ ( 100W X 2ch ) FREQUENCY RESPONSE (1W, 0+/-1dB/8Ω): SPEAKER OUTPUT: 10HZ - 100KHZ ( 100W X 2ch ) H/F SPEAKER OUTPUT: 10HZ - 100KHZ ( 100W X 2ch ) TOTAL HARMONIC DISTORTION: BALANCED & UNBALANCED (Line 1,2,3) INPUT: 0.006%(50W) ( 200W X 4ch) SIGNAL TO NOISE RATIO: BALANCED, UNBALANCED / PHONO MM: 108dB / 106dB / 79dB (MM) ( 200W x 4ch ) DAMPING FACTOR: SPEAKER & H/F SPEAKER OUTPUT: >150 ( 200W X 2ch ) SUBSONIC FILTER WITH ON/OFF SWITCH: 3dB: 50Hz 9 ( 1W x 4ch ) TONE CONTROL WITH ON/OFF SWITCH: BASS (100Hz) / TREBLE (10KHz):+/-15dB ( 1W x 2ch [Speaker Output] ) X-OVER WITH ON/OFF SWITCH: HPF (-3dB): 600Hz - 6KHz ( 1W x 2ch [H/F Speaker Output] ) ANALOG AUDIO INPUTS: 1 x PHONO Unbalanced RCA 3 x LINE Unbalanced RCA 1 x Balanced XLR ANALOG AUDIO OUTPUTS: 1 x SUBWOOFER OUT PHONO: MM/MC with variable EQ TURNOVER (FLAT): 300Hz (+7.7dB@100Hz) 400Hz (+11.7DB@100HZ) 500Hz (+13dB@100Hz) [RIAA] 700Hz (+14.5dB@100Hz) ROLL-OFF (FLAT): 1.6KHz (-16dB@10kHz) 2.1KHz (-13.7dB@10kHz) [RIAA] 3.18KHz (-11dB@10kHz) 3.4KHz (-8dB@10kHz) 6.36KHz (-5dB@10kHz) AUDIO IN/OUT SETTING: TRIGGER: 3.3 V ~12V AUDIO CONTROL: 3-Band EQ w/ adjustable gain Pure Direct Sub Sonic Filter A/B Speaker Selector CONTROL: Bluetooth Remote Controller (included) IR INPUT: 38 kHz Infrared Ray (Operating Distance within 10 m) DESIGN BODY: High-purity aluminum DIMENSIONS (L x W x H): 16.9" x 12.4" x 4.8" DIMENSIONS with FEET: 16.9" x 13.7 x 5.11 WEIGHT: 37 lbs
